Esilient 10 Inch Gate Valve Oil Bolted Bonnet Gate Valve API600 Standard
- Model Number:
- CX-GTV-14
- Minimum Order Quantity:
- 1PC
- Prices:
- Negotiable
- Packaging Details:
- Plywood packing
- Delivery Time:
- depends on the qty of order
- Payment Terms:
- L/C, D/A, D/P, T/T, Western Union, MoneyGram
- Supply Ability:
- 1000PCS per month
- Place of Origin:
- WENZHOU,CHINA
- Certification:
- ISO, CE,API
Detailed Product Description
| Size: | 2~48" | Pressure: | CL150~2500 |
|---|---|---|---|
| Material: | Stainless Steel | Certifcate: | CE, API,ISO |
| Operation: | Handwheel,Worm Gear | ||
| High Light: | bolted bonnet gate valve , handwheel gate valve | ||
API600,rising stem,bolted bonnet,solid wedge,10 inch resilient gate valve,flanged, class 300
Applicable Standards:
Gate valve, API 600
Steel valves, ASME B16.34
Face to face ASME B16.10
End Flanges ASME B16.5/ASME B16.47
Butt Welding ends ASME B16.25
Inspection and test API 598
Material: SS304/316/304L/316L ( CF8/CF8M/CF3/CF3M), WCB, WCC, LCB,LCC,WC6,WC9, C5,C12, etc
Size Range: 2"~36"
Pressure Rating: ASME CL, 150, 300, 600, 900, 1500, 2500
Temperature Range: -50°C~650°C
Design Description:
- Outside Screw and York
- Bolted Bonnet and Pressure Seal
- Flexible wedge, fully guided
- Welding seat rings or Renewable seat rings
- Rising stem and non-rising stem
- Available with gear operator
- Flange Ends & Buttwelding Ends
- Low torque design, smooth surface stem.
| Brand | CX VALVE |
| Structure | GATE |
| Valve Material | CX provide cast steel, stainless steel, special alloy, Aluminum Bronze,etc |
| Valve Type | CX Gate Valve |
| Valve Test | 100% quantity tested before delivery |
| Valve Guarantee | 18 months after shipments and 12 months after installed |
| Valve Structure | Cast Steel Gate Valve |
| Valve Delivery | 25- 50 days |
| Valve Sample | Sample Available by CX Valve |
| Valve Color | Customer request |
| Valve Packing | Plywood Case for Gate Valve |
| MOQ | 1 Set |
| Valve Certificate | API6D/CE/ISO9001/ISO14001 |
| Place of Origin | Zhejiang, China (Mainland) |
| Delivery Detail: | Shipped in 25-50 days after payment |
| Port | Shanghai Or Ningbo |
| Payment Terms | L/C,D/A,D/P,T/T, Western Union |
Application & Function:
CX Cast steel Gate valves are primarily used for stop valves fully opened or fully closed. They are not normally considered for throttling purposes, but more for slurries, viscous fluids, etc. Gate valves are characterized by a traveling wedge, which is moved with the operation of the stem nut. The wedge travels perpendicular to the direction of the flow. Gate valves usually have a minimum pressure drop when fully open, provide tight shut-off when fully closed, and remain relatively free of contamination buildup.
Accessories:
Accessories such as gear operators, actuators, bypasses, locking devices, chain wheels, extended stems and bonnets for cryogenic service and many others are available to meet the customers' requirements.
| ITEM | PARTS | MATERIAL | ||
| Trim1 | Trim5 | Trim8 | ||
| 1 | BODY | ASTM A216-WCB | ||
| 2 | SEAT RING | ASTM A216-WCB+Cr13 | ASTM A105+STL#6 | ASTM A105+STL#6 |
| 3 | WEDGE | ASTM A216-WCB+Cr13 | ASTM A105+STL#6 | ASTM A216-WCB+Cr13 |
| 4 | STEM | ASTM A182-F6a | ||
| 5 | GASKET | SPW SS 304+GRAPHITE | ||
| 6 | BONNET | ASTM A216-WCB | ||
| 7 | NUT | ASTM A194-2H | ||
| 8 | STUD | ASTM A193-B7 | ||
| 9 | BACK SEAT | ASTM A276-410 | ||
| 10 | PACKING A | GRAPHITE | ||
| 11 | SPACER RING | ASTM A276-410 | ||
| 12 | PACKING B | GRAPHITE | ||
| 13 | PACKING C | |||
| 14 | GLAND | ASTM A276-410 | ||
| 15 | GLAND FLANGE | ASTM A216-WCB | ||
| 16 | GREASE FITTING | CARBON STEEL | ||
| 17 | STEM BUSHING | ASTM A439 D-2 | ||
| 18 | RETAINING NUT | ASTM A29-1025 | ||
| 19 | HANDWHEEL | DUCTILE IRON | ||
| 20 | NUT | ASTM A29-1025 | ||
| 21 | EYE BOLT | ASTM A193-B7 | ||
| 22 | NUT | ASTM A194-2H | ||
| 23 | PIN | ASTM A29-1025 | ||
| 24 | NAMEPLATE | SS 304 | ||
